Big 3 Engine and Transmission

Installation Reference Terms and Conditions

Engine (Failure to complete the following will void Warranty)

- Determine why the original engine failure occurred and make appropriate repairs.

REPLACEMENT OF ALL PARTS RELATED TO PRIOR FAILURE AND ALL SENSORS THAT MAY BE CONTAMINATED BY THE MOTOR BEING REPLACED IS REQUIRED. FAILURE TO REPLACE THESE ITEMS RESULTING IN ENGINE DAMAGE OR OTHER REPAIR INCLUDING DIAGNOSTIC AND ADMINISTRATIVE OR TECHNICAL SUPPORT FEES WILL BE THE RESPONSIBILITY OF THE CUSTOMER AND THEIR INSTALLER AND NOT BIG 3 ENGINES OR ANY AFFILIATED BIG 3 ENGINES SHOP. AS OF JANUARY 2023 BIG 3 WILL NO LONGER OFFER FREE SUPPORT TO CERTIFIED SHOPS FOR REPAIRS CAUSED BY OR RELATED TO FAILURE TO FOLLOW THE DIRECTIONS INCLUDED WITH YOUR MOTOR OR POSTED ON OUR WEBSITE. FOR EXAMPLE, THESE ITEMS MUST BE REPLACED- VARIABLE VALVE TIMING SOLENOIDS, OIL CONTROL VALVES, OR ACTUATOR/SPROCKETS, VARIABLE DISPLACEMENT SOLENOIDS, VLOM, MODULES, SENSORS, FILTERS, SENDING UNITS INCLUDING ALL AFM, DOD, MDS AND RELATED PARTS. INTAKE MANIFOLDS AND ALL RELATED PARTS MUST BE REPLACED OR SUITABLY RECONDITIONED AND FAILURES RELATED TO FORIEGN OBJECT OR CONTAMINATION OF THE MOTOR ASSEMBLY WILL NOT BE COVERED UNDER YOUR WARRANTY.
- Insure this engine is the same application as the one being replaced.
- Clear all computer diagnostic codes from the vehicle prior to installing.
- Exchange the oil pan and pick up tube, Exchange the intake and throttle body, Accessories, or other differing components to ensure proper fit.
- Inspect and replace all gaskets & seals (front seal, rear main seal, valve cover gaskets, oil pan gaskets).
- On crankshaft bolts that are drilled through sealant must be applied to avoid leaks.
- Install new thermostat & gasket (warranty will be void if engine heat tab is melted or removed)
- Replace the timing belt, Inspect timing chain, guides, sprockets, distributors, etc. and replace as necessary.
- Remove all 'cap-plugs' orifice covers.
- Replace water pump.
- Install replacement spark plugs & wires. Test ignition coils and replace if necessary.
- Exchange the flex-plate or flywheel and bolts. Replace clutch and service transmission if necessary.
- Exchange attached accessory items to insure proper fit (mounts, intake/exhaust manifold, accessories, harness, sensors).
- Disable fuel/ignition before attempting to start engine. This will allow the oil to prime as indicated by the manufacturer. Verify oil pressure with a mechanical gauge before attempting to start engine. Oil starvation is not covered.
- Replace engine oil, oil filter, air filter, fuel filters, coolant-antifreeze.
- Drain excess oil and coolant from exhaust system.
- If equipped with an engine oil cooler the radiator or external cooler must be replaced.
- Insure the cooling system is flushed and functioning properly.

IF YOU EXPERIENCE A WARRANTY ISSUE, DO NOT DISASSEMBLE YOUR ENGINE OR TRANSMISSION ASSEMBLY. UNAUTHORIZED DISASSEMBLY OR UNAUTHORIZED REPAIR WILL COMPLETELY VOID YOUR WARRANTY.

What is NOT Covered or Guaranteed to be included:
The engine you receive may or may NOT include some additional accessories and extra parts. If included these parts are sold AS-IS with NO WARRANTY. Examples of these non-warranty parts include switches, sensors, cables, coils, wires, injectors, electronics, belts (including timing belt/chain), hoses, water pumps, brackets, intake/exhaust manifolds, oil pans, turbos/superchargers (if equipped), alternators, starters, and power steering pumps. These are included for your convenience and to aid in installation. Some of these items may not work for your application and must be changed. Warranty does NOT cover labor, diagnostic, towing or rental car costs.

Transmission (Failure to complete the following will void Warranty)

• Scan, record and clear all codes before removing the original unit.

• Replace all seals.
• Install new filter kit.
• Flush and inspect cooling lines.
• Transmission cooler must be replaced regardless of condition.
• Align and engage torque converter into front pump.
• Fill transmission with manufacturer specified fluid.
• Adjust throttle position sensor cable.
• Late model transmissions must be programmed, failure to do so will cause transmission damage.

Engine Swapping (Failure to complete the following will void Warranty)

• Verify that you have all necessary equipment to perform the Engine and/or Transmission swap that you are performing.
• You are required to have the installation performed by a certified technician or performance and repair shop.
• Engine or transmission damage as a result of improper installation is not covered. (i.e. dry sump engine w/o proper oiling equipment, Wet-sump engine used in rear engine layout or used for track conditions without proper oiling equipment installed).
• Verify that accessories and exhaust will fit your application before installation. Oil pans, starters, intakes and accessory drives may have to be changed out for an appropriate unit in order to function properly. (i.e. many newer engines do not have power steering pumps, this may have to be added by utilizing a specialized accessory drive, Dry sump corvette or camaro type engines will require an aftermarket dry sump system, Many late-model engines may require several accessories and Ecu/Tcm programming in order to work correctly, motor and transmission mounts, custom drive shafts, adapters, custom exhaust equipment, etc.).
• Big 3 is not responsible for advising any shop or customer on how to install an engine or transmission into a vehicle for which it was not intended. We do not provide that type of support at this time. Late model engines and transmissions must be programmed before starting for the first time, failure to perform this procedure can cause damage and is not covered under your warranty.
• Make sure your harnesses are correctly installed, verified by a certified technician, before attempting to start your vehicle.
