PONTIAC 400 CUSTOM 450HP++

PONTIAC OEM ENGINE BLOCK

CUT TO 4.150

ALIGN HONE

DECK AND SQUARE

SUNNEN HONE

FULLY CORRECTED SEASONED BLOCK

PONTIAC 400 10/10 CRANKSHAFT

FULL DIGITAL BALANCING PROCEDURE

PONTIAC CONNECTING ROD-SUNNEN RESIZE CLEVITE BEARING

HIGH COMPRESSION PISTON-MORE OPTIONS AVAILABLE

411NP 30

Sealed Power Pistons

Bore (in.): 4.150 in.

Bore (mm): 105.410mm

Stroke: 3.750 in.

Rod Length: 6.625 in.

Piston Style: Flat top, with four valve reliefs

Compression Height (in.): 1.700 in

Wrist Pin Style: Press-fit

Pin Diameter (in.): 0.980 in.

Piston Ring Thickness: 5/64 in. x 5/64 in. x 3/16 in.

CAMSHAFT OPTION

COMP Cams 51-223-4 - COMP Cams Xtreme Energy Camshafts

Hydraulic Flat Tappet, Advertised Duration 268/280, Lift .477/.480
COMP Cams 51-224-4 - COMP Cams Xtreme Energy Camshafts

Hydraulic Flat Tappet, Advertised Duration 274/286, Lift .488/.491

COMP Cams 51-116-3 - COMP Cams Factory Muscle Camshafts

Hydraulic Flat Tappet, Advertised Duration 292/303, Lift .516/.516

PREMIUM DELCO LIFTERS WITH HARDENED FOOT-BREAK IN REQUIRED

1.65 Ratio 7/16" DNA® Aluminum Roller Rocker Arms – COMP OPTION AVAILABLE

OEM PONTIAC 400 CYLINDER HEADS

3 ANGLE BACK CUT VALVE SEATS

PAC AND COMP SPRINGS LOCKERS AND RETAINERS MATCHED TO CAMSHAFT

ARP GUIDE STUDS AND HARDENED PUSHRODS

ENGINE COLORS OPTIONAL

MAHLE, FELPRO, AND ENGINETECH GASKETS

MELLING OIL PUMP

DRESSED INTAKE TO OIL PAN INCLUDES:

Edelbrock 7156 - Edelbrock Performer RPM Intake Manifold

STANDARD DECK DUAL PLANE

1,500-6,500 RPM OPERATING RANGE

EDELBROCK BLACK OR CHROME VALVE COVERS (DIE CAST ALUMINUM PONTIAC ALSO AVAILABLE +$258)

SUMMIT RACING ALUMINUM TIMING COVER

MILODON GOLD IRIDITE OILPAN 4QT OR 7QT AVAILABLE

ARP AND ROGUE BOLT HARDWARE

OPTIONAL FULL ROLLER CONVERSION CAMSHAFT OPTION +$1279

COMP Cams 51-423-11 - COMP Cams Xtreme Energy Camshafts

Camshaft, Hydraulic Roller Tappet, Advertised Duration 276/282, Lift .502/.510

COMP Cams 51-433-11 - COMP Cams Xtreme Energy Camshafts

Camshaft, Hydraulic Roller Tappet, Advertised Duration 288/294, Lift .520/.540

Howards Cams 414645-10 - Howards Cams 4/7 Swap Camshafts

Camshaft, 4/7 Swap, Hydraulic Roller Tappet, Advertised Duration 266/274, Lift .485/.475

HOWARDS RETROFIT ROLLER LIFTERS

TURN KEY PACKAGE:

B3 BRAWLER 750CFM CARBURETOR-OTHER OPTIONS AVAILABLE-EFI ALSO AVAILABLE

Mechanical Secondary, 4-Barrel, Square Bore, Black Powdercoat, Red Anodized Metering Blocks

EDELBROCK AIR CLEANER BLACK OR CHROME – PONTIAC AVAILABLE WITH PONTIAC COVER UPGRADE

PERTRONIX FLAME THROWER HEI IGNITION

TAYLOR CABLE PLUG WIRES

PREMIUM SPARK PLUGS

WATER PUMP-OUTLET-THERMOSTAT

FULL SERPENTINE KIT

Pontiac Serpentine Conversion - AC, Power Steering & Alternator

CVF RACING SERPENTINE FRONT DRIVE BLACK OR CHROME

• 1 Belt Crank Pulley
• 1 Belt Alternator Pulley
• 1 Belt Keyway Power Steering Pulley
• 3 Idler Pulleys
• Power Steering / Alternator Bracket
• Sanden AC Compressor Bracket
• ALTFAN - Universal alternator
• SANDEN 508 COMPRESSOR
• SAGINAW KEYWAY POWER STEERING PUMP
• 140 AMP GM 1 WIRE ALTERNATOR
• GATES 8 RIB BELT

OPTIONAL UPGRADE AVAILABLE AT +$2788 WITH REMACHINING COST -530HP +

Speedmaster PCE281.2165 ALUMINUM CYLINDER HEADS(THE ONLY KIND CURRENTLY AVAILABLE FOR THIS)

Bronze valve guides
* CNC-finished faces and bolt holes for extreme accuracy
* T6 heat-treated gravity die-cast construction (alloy heads only)
* OEM accessory bolt patterns
* Plenty of material for upgrading to larger horsepower applications
* Machined for screw-in studs and guide plates
* Flame-hardened valve seats for use with all fuel
