Ford Performance Parts 363 C.I.D. Boss Short Block Assemblies

Start with the right foundation for your Blue Oval build--start with Ford Performance Parts 363 c.i.d. Boss short block assemblies. Build a powerful 8.2 in. deck engine for your vintage muscle, street rod, Fox body, or late model Mustang by starting with the same short block used in the 500 hp Z363 crate engines. These Ford Performance Parts Boss short block assemblies take the bore out to 4.125 in. for 363 stroked cubes of power. Plus, strength from within is provided by the forged crankshaft and I-beam connecting rods. Power your next project with Ford Performance Parts 363 c.i.d. Boss short block assemblies.

Additional technical specifications:

* Engine type: 302 based small block Ford
* Bore x stroke: 4.125 in. bore x 3.400 in. stroke
* Block: Boss 4-bolt main block M-6010-BOSS302
* Piston to Deck Height: .01 in." below deck (nominal)
* Crankshaft: SCAT forged steel
* Connecting rods: SCAT forged steel I-beam connecting rods with floating pins and ARP bolts
* Pistons: Mahle forged aluminum, 1.5mm, 1.5mm, 3.00mm rings, valve reliefs for X306, X307, Z304DA, Z304P, N351, and other inline valve Windsor cylinder heads
* Pistons designed for 20 degree valve angle heads and will fit stock or most spread valve guide centerlines; 6cc valve pockets, check piston to valve clearance
* Compatible with most aftermarket performance cylinder heads
* Designed for M-6049-X306//X307/Z304DA/Z304P and N351 cylinder heads. Not designed for production 302/351W or M-6049-Y302/Y303/X302/X303/X304/X305 cylinder heads
* Hydraulic roller camshaft compatible
* Recommended cylinder head fasteners M-6065-BOSS head bolts or M-6014-BOSS studs depending on application
* Requires head gaskets M-6051-R351
* Internally balanced; requires "0" balance flywheel and damper
* High performance harmonic balancer M-6316-D302 recommended
* High-volume oil pump M-6600-D2 recommended
* 302 bolt pattern oil pan and timing cover
* Built with all new parts
* Photo and specifications may vary

Ford Racing parts are sold "as is" without any warranty whatsoever. The entire risk as to the quality and performance of such parts is with the buyer. The buyer, and not the manufacturer, distributor, or retailer, assumes the entire cost of all necessary servicing or repair. Parts thought to be defective upon initial installation can be returned for inspection and will be handled case-by-case. The exception to this warranty is that Ford Racing Performance warrants to the original retail purchaser for 12 months or 12,000 miles, whichever comes first, that it will repair or replace, at its option, using new or remanufactured parts, Ford Racing Performance Parts engine covered parts that, after inspection, are found to have failed due to a defect in factory-supplied materials or workmanship. The customer must contact Ford Racing Performance Parts directly at (586) 468-1356 regarding this warranty.

Ford Racing warrants the following parts for 12 months/12,000 miles from the time of installation when installed by a Ford or Lincoln Mercury dealer prior to the vehicle reaching either 36 months or 36,000 miles (whichever occurs first) from the vehicle warranty start date when they are found to be defective in factory-supplied material or workmanship:

* FMS-M-6066-M463V

* FMS-M-6066-M463P

* FMS-M-6066-M463V7

* FMS-M-6066-M463P7

* FMS-M-6066-M463V8

* FMS-M-6066-M463P8

* FMS-M-6066-SGT

Ford Racing warrants the following parts for 24 months/24,000 miles:

* FMS-M-6007-A50NA

* FMS-M-6007-A50SC

* FMS-M-6007-M50

* FMS-M-6007-M54

* FMS-M-6007-X302

* FMS-M-6007-X302B

* FMS-M-6007-X302E

* FMS-M6007X427FFT

* FMS-M6007X427FRT

* FMS-M6007Z363FT

* FMS-M6007Z363RT

* FMS-M6007Z427FFT

* FMS-M6007Z427FRT

This warranty replaces the existing manufacturer's warranty for engine, driveline, and suspension parts with a 12-month or 12,000-mile warranty. Installation of these products by anyone other than a Ford dealer may void the vehicle powertrain warranty.

Techline 1-800-367-3788 Page 1 of 2 IS-1850-0229 Factory Ford shop manuals are available from Helm Publications, 1-800-782-4356 Please visit www.fordracingparts.com for the most current instruction information ! ! ! PLEASE READ ALL OF THE FOLLOWING INSTRUCTIONS CAREFULLY PRIOR TO INSTALLATION. AT ANY TIME YOU DO NOT UNDERSTAND THE INSTRUCTIONS, PLEASE CALL THE FORD RACING TECHLINE AT 1-800-367-3788 ! ! ! OVERVIEW: The M-6009-363 engine short block assembly is used to build the M-6007-Z363FT and M-6007-Z363RT engines. These engines are intended for high performance or street rod vehicles (not subject to emission restrictions). The pistons will accept M-6049-X306, M-6049-X307, and M-6049-Z304D cylinder head assemblies. Piston to valve clearance needs to be checked. Short block components include: M-6010-BOSS302 block. Forged aluminum 4.125" Mahle pistons with a 6cc dish and full floating pins & pin locks. Forged I beam rods bushed for floating pins (.927 diameter). Forged Steel 3.400" stroke crankshaft. Clevite rod and main bearings. Notes: 1. PISTON TO VALVE CLEARANCE MUST BE CHECKED with any high lift camshaft. Recommended minimum clearance is .100" intake, .125" exhaust, .060" radial. 2. Rod shoulder to cam lobe clearance must also be checked. If required, .050" minimum clearance. 3. The crank has been internally balanced to use neutral balance crankshaft dampers and flywheels. 4. M-6316-D302 "0" balance damper recommended. 5. M-6375-D302AB "0" balance manual transmission 157 tooth flywheel recommended. 6. A performance oil pan and pickup tube to suit the intended vehicle application should be used. (check pickup tube to crankshaft clearance), also check pick up tube to bottom of pan distance (½" +/- 1/16") 7. M-6600-D2 Oil pump recommended. 8. Head gasket M-6051-R351 recommended for most applications. M-6009-363 Engine Short Block INSTRUCTION SHEET NO PART OF THIS DOCUMENT MAY BE REPRODUCED WITHOUT PRIOR AGREEMENT AND WRITTEN PERMISSION OF FORD RACING PERFORMANCE PARTS. Techline 1-800-367-3788 Page 2 of 2 IS-1850-0229 Factory Ford shop manuals are available from Helm Publications, 1-800-782-4356
